Users Manual Sonic Knife w/500 Assembly Drawings Mechanical •••• 49
H Frame Assembly Parts List
Item Part # Description Qty Item Part # Description Qty
1 427026 NUT, ADJUSTMENT 1 19 427061 BUSHING INSULATOR 4
2 999142 BUSHING, 1/2 X 3/4 X 2" 2 20 427062 INSULATOR, KNIFE HOLDER 2
3 427035 SPRING, COMPRESSION (NOT SHOWN) 1 21 990091 10-32 X 1/2 BUTTON HD CAP SCREW 4
4 577035 SHAFT, EXTENSION 1 22 990256 1/4" STEEL PIN 1
5 991427 BUSHING, 1/2 X 13/16 X 1/2" 1 23 990058 8-32 x 1/4" SET SCREW 2
6 991428 NUT, JAM 5/16-24 1 24 577060 BRACKET, NUT 1
7 572040 SHAFT, SPRING MOUNT 1 25 990029 6-32 X 1/4" FLAT HD CAP SCR 1
8 577036 SHAFT, SMALL EXTENSION 1 26 990050 8-32 X 1/4" SOCKET HD CAP SCREW 1
9 999146 BUSHING, 3/8 X 1/2 X 1/2" 2 27 572049 TIE PLATE 1
10 577029 BRACKET, LIFTER 1 28 990144 # 10 FLAT WASHER 2
11 577034 SHAFT, EXTENSION 1 29 990326 SNAP RING, 1/4 E-RING 1
12 577032 SHAFT, ADJUST 1 30 577078 H FRAME 1
13 577019 SHAFT, POST 2 31 577056 KNIFE BLADE 1
14 990081 HEXAGON SOCKET HEAD CAP SCREW 2 32 990121 1\4-20 X 5/8" SOCKET HD CAP SCREW 2
15 990080 10-32 X 3/8" SOCKET HD CAP SCREW 2 33 990119 1/4-20 X 3/8 CAP SCREW 6
16 577053 BRACKET, SNUBBER MOUNT 1 34 999008 BEARING, R12FF 1
17 577054 BRACKET, INSULATOR PLATE 1 35 577077 BRACKET, HORN MOUNT 1
18 577055 BRACKET, KNIFE MOUNT 1 36 577077 BRACKET, HORN MOUNT 1
