Page 47
Users Manual Sonic Knife w/500
Assembly Drawings Mechanical •••• 47
Infeed Conveyor Assembly Parts List
Item Part #
Description
Qty
1
574097 ROLLER, BOTTOM
1
2
999014 BUSHING, 1/4 X 3/8 X 3/4"
4
3
574096 ROLLER, TOP
1
4
574095 SHAFT, SNUBBER
2
5
999157 BUSHING, 3/8 X 5/8 X 1"
2
6
990325 SNAP RING, 3/16 E-RING
2
7
991451 COMPRESSION SPRING, .156 OD X .132 ID
2
8
991493 SPRING, COMPRESSION (SNUBBER)
2
9
574081 WEB GUIDE, RH
1
10
574080 WEB GUIDE, LH
1
11
196028 KNOB, BLACK (GLOSS)
1
12
574089 LOWER BRIDGE PLATE
1
13
574086 BASE CONVEYOR BRACKET
1
14
574098 SNUBBER PAD
1
15
574090 SNUBBER BRACKET
1
16
574085 SNUBBER LOCK PLATE
1
17
574083 SNUBBER TIE PLATE
1
18
990118 1/4-20 X 3/8 CAP SCREW
4
19
990313 THUMB SCREW KNOB, #10
1
20
990072 8-32 X 1/" FLAT HD CAP SCREW
2
21
990087 HEXAGON SOCKET HEAD CAP SCREW
1
22
574084 WEB GUIDE BASE
1
23
574094 SPRING INSERT
2
24
990401 RIVIT, 3/18 C 3/8" FLAT HEAD
2
25
990261 3/16" SNAP RING
2
26
991481 BEARING, 3/16 X 5/16" FLANGE BUSHING
2
27
991484 GEAR, 36T 1/4" BORE
1
28
571223 COVER, GEAR
1
29
574082 SHAFT, ADJUSTING
1
30
990028 6-32 X 3/8" FLAT HD CAP SCREW
2
31
574087 BASE CONVEYOR, LH
1
32
574088 BASE CONVEYOR, RH
1
33
574091 TOP CONVEYOR, LH
1
34
574092 TOP CONVEYOR, RH
1
35
574093 UPPER BRIDGE PLATE
1
36
990015 6-32 X 1/4 SOCKET HD CAP SCR
4
37
990051 8-32 X 3/8 SOCKET HD CAP SCR
2
38
990082 10-32 X 5/8 SOCKET HD CAP SCR
4
39
990006 4-40 X 1/4 SOCKET HD CAP SCR
4
40
991210 KNOB, ADJUST
2
41
574099 SHAFT, ADJUSTMENT KNOB
2
42
571224 COVER, SNUBBER
1
