KBC Networks ESML6-FL2 - Manual (Page 9)

Ethernet Switch User Manual
Manual_sw-ESML6-FL2-Rev1106
Copyright © KBC Networks Ltd. Page 8 of 64 www.kbcnetworks.com
2.3 Log in using a web browser
To access the switch via a web browser, the switch needs to be connected from one of its
RJ45 ports by a straight-through cable to the computer. The user can view or modify the
IP address once in the management software.
MAC address： 000060006000
IP address： 192.168.0.2
Subnet mask： 255.255.255.0
Default gateway： 192.168.0.1
Access the web in the following way:
1. Start a web browser and enter the appropriate IP address, press the enter key to
open the connection as shown in Fig 2-10:
2. Enter the user name “admin” and password “123” in the presented page and
click on the “Log in” button.
3. The main web page will be displayed as below:
Fig 2-12 Main Web Page
Fig 2-10 Start Web Management
Fig 2-11 Log in to the Web Interface
