13. SNMP
If the MIB is installed correctly at the management end, any SNMP-running management
software can manage the switch. SNMP is a protocol to control the transmission between
manager and agent. SNMP V1 is supported.
This page is used to define host pc as trap manager and enter the SNMP group name.
The user can also define a name, location and contact for the switch.
Item Description
Name Enter the switch name.
Location Enter the switch location
Contact Enter the group name
Table 5-8 SNMP Parameters
The group name can be used as a password in the following way:
Item Description
Read only Enable the request with this name to display the MIB information.
Read write
Enable the request with this name to display and configure the MIB
information.
Table 5-9 SNMP
The trap manager is the host station to receive traps which are generated by the switch.
If a trap manager is not defined, a trap won’t be issued. To create a trap manager enter
an IP address and a group name.
Fig 5-23 SNMP
