Ethernet Switch User Manual
Manual_sw-ESML6-FL2-Rev1106
Copyright © KBC Networks Ltd.
Page 9 of 64
www.kbcnetworks.com
3 Console Management using the Console
Port & Telnet
3.1 Main Menu
Menu options and functions through the console port and Telnet are identical see Fig 3-1.
Once in the main menu, as shown below, use the keys in Table 3-1 to navigate the
system. Within the main menu there are 6 options.
Fig 3-1 Main Menus
