b) MAC Age Interval
This feature is used to specify the time to keep an inactive MAC address in the switch
address table. The valid range of time is 300-765 seconds. The default value is 300
seconds.
c) Broadcast Storm Filtering
This feature is used to configure the broadcasting storm control. When this feature is
enabled the threshold value can be set for the port. The threshold value set is the
percentage of the bandwidth of the broadcasting flow for the port. When the threshold
value is exceeded the control becomes enabled. The options are: 5%，10%，15%，
20%，25%.
To set the desired values select and press the enter key to configure the filtering
mode. Press the space key to select the value.
Fig 3-26 MAC Age Interval
Fig 3-27 Broadcast Storm Filtering
