4.7 Commands for VLAN
Commands Description
add vlan vid 1> protocol ports
[tag|untag]
create VLAN group.
: the name assigned to the VLAN. The valid strings
are 15 max.
: the VLAN ID assigned to the VLAN. The valid
values are 1~4094.
: to assign a protocol defined by the user. The
valid values are 0~18.
: port number. Eg. add vlan v1 vid 2 protocol 0
ports 1,2 tag
config vlan protocol
assign a protocol to the VLAN
: the VLAN name. Eg. config vlan v1 protocol 5
config vlan addport
[tag|untag] add one or more ports to the VLAN. The user can assign
tagged or untagged port. Eg. config vlan v1 addport 3,4 tag
config vlan delport
delete one or more ports from the VLAN.
Eg. config vlan v1 delport 3,4
Config vlan tag
configure the tagged port in the VLAN.
Eg. config vlan v1 tag 1
config vlan untag
configure the untagged port in the VLAN.
Eg. config vlan v1 untag 2
delete vlan
delete the VLAN by name
Eg. del vlan v1
delete vlan vid <1~4094>
delete the VID by name
Eg. del vlan vid 2
show vlantbl display the VLAN name.
show vlantblindex display all switch names
enable vlan gvrp configure VLAN as port-based 802.1Q with GVRP.
disable vlan gvrp configure VLAN as port-based 802.1Q without GVRP.
show vlanstate display the VLAN status
show prtcl vlantbl display the VLAN protocol type.
config vlan pvid <1~4094> ports
configure the PVID of each port.
