4.3 Configuring the Switch - Advanced Configurations
Command Description
Age-out Time
Enable fdbage enable the MAC address auto aging time feature.
Disable fdbage disable the MAC address auto aging time feature.
Config fdbage
configure the MAC address auto aging time. The valid value is
300~765 secs
Show fdbage display the aging time.
Broadcast Storm Filter
Enable bsf[5|10|15|20|25] enable or configure boadcasting storm filter, eg. enable bsf 10.
Disable bsf disable the broadcasting storm filter.
Show bsf display the configuration of the broadcasting storm filter
Priority Queue Service
Config
qos[fcfs|wrr|strict]>
configure the priority queue service. The following options can
be specified:
Fcfs: first come first service
Wrr: weighting round robin
Strict: higher priority frames are transmitted before lower
priority frames.
: high weighting priority, the valid value is 1-7. only
effective in WRR.
Eg. Config qos fcfs
Config qos wrr 5 1
Enable qdlyb<1~255>
To enable lower queue latency threshold values. Values need to
be between 1 & 255ms. Eg. enable qdlyb 200
Disable qdlyb disable the low queue latency threshold value.
Show qos display the queue configurations.
Config qospolicylist>
configure the policy of QoS. The priority of 0 to7 can be
mapped to higher or lower queues
: belongs to higher priority with effective
values from 0 to 7
Eg.config qospolicy 0~3
