Technical details
Operating Manual PSSu E F 2DOR 8(­T)(­R)
21334­EN­07 28
Relay outputs 312225 314225 315225
Utilisation category
In accordance with the
standard
EN 60947­4­1 EN 60947­4­1 EN 60947­4­1
Safety contacts, AC1 at 250 V 250 V 250 V
Max. current 8,0 A 8,0 A 8,0 A
Min. current 10,00 mA 10,00 mA 10,00 mA
Max. power 2000 VA 2000 VA 2000 VA
Safety contacts, AC1
with condensation at
– 30 V 30 V
Min. current – 10 mA 10 mA
Max. current – 8 A 8 A
Max. power – 240 VA 240 VA
Safety contacts, DC 1
at
24 V 24 V 24 V
Max. current 8,0 A 8,0 A 8,0 A
Min. current 10,00 mA 10,00 mA 10,00 mA
Max. power 192 W 192 W 192 W
Safety contacts, DC 1
at
– – 60 V
Max. current – – 1,66 A
Min. current – – 10 mA
Max. power – – 100 W
Utilisation category
In accordance with the
standard
EN 60947­5­1 EN 60947­5­1 EN 60947­5­1
Safety contacts, AC15
at
230 V 230 V 230 V
Max. current 3,0 A 3,0 A 3,0 A
Safety contacts, AC15
with condensation at
– 30 V 30 V
Max. current – 3 A 3 A
Safety contacts DC13
(6 cycles/min) at
24 V 24 V 24 V
Max. current 5,0 A 5,0 A 5,0 A
Safety contacts, DC1
at
– – 60 V
Max. current – – 0,7 A
Utilisation category in ac­
cordance with UL
Voltage 250 V AC G.U. (same po­
larity) 250 V AC G.U. (same po­
larity)
–
With current 3,0 A 3,0 A –
Voltage 24 V DC G. P. 24 V DC G. P. –
With current 3,0 A 3,0 A –
Pilot Duty B300, R300 B300, R300 –
