DM500™ and DM550™ Series Digital Mailing System Operating Guide
SV61436 Rev. D 9 - 17
10. Grasp the printhead
stand-off and lift the print-
head up and out.
11. Discard the old printhead.
12. Locate the new print-
head. Remove the
orange packing tab from
the new printhead as
shown here.
13. Install the new printhead
in the printhead slot.
14. Close the printhead cover and push the prinhead tab back into place.
15. Close the main cover; the “Initializing Printhead” screen appears
16. Once the initializing is complete, the “Print Test Pattern” screen opens
and prompts you to “Press Tape or print an envelope”.
You must perform the print test at this time. Follow the prompts, or refer
to Printing a Test Pattern in this chapter for more information.
17. Proceed to Changing the Wiper Blade Assembly section.
