1138 Parts Diagram Key
Key No. Item Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
888DD2
889DD
821DD
668DD
882DD
925DD
SA1632RD06 (2)
902DD
899DD
1454DD
904DD (2)
905DD
SA1632FT06 (2)
898DD
SN1632HX
1374HCJV (2)
394HC
663DD
1071DD
1444DDJB
1452DD
1452DDCL
655DD (2)
1095DD
PA1332RD04 (2)
656DD
653DD
43AS
906DD
658DD
654DD
1094DD
643DD
645DD
647DD
SC1332SC02 (3)
SA1332FP04
659DD
840DD2
694DD
1453DD
519AJV Cylinder
Outer Ring
O-Ring 1/16 ID NBR
Check Valve
O-Ring 1/2 ID NBR
Bomb Retainer
8-32 x 3/8 RHMS
Ground Stud Head
Head Handle
Funnel
Standoff 8-32 x 5/8 M-F
Standoff 8-32 x 3/8 M-F
8-32 x 3/8 FHMS
Locator Cap
8/32 Hex Nut
O-Ring 1/8 ID FKM
O-Ring 3/8 ID FKM
Contact Bushing
Quad Ring 2.88 ID NBR
O-Ring 1-5/8 ID NBR
Head
Head for Chlorine Service
Electrode Spacer
Electrode
6-32 x 1/4 RHMS
Reducer Bushing
Electrode Nut
Capsule
Capsule Holder
Insulator
Electrode Washer
Electrode
Check Valve
Water Diffuser
Anti-Rotator
6-32 x 1/8 SHSS
6-32 x 1/4 FHMS
O-Ring 5/32 ID NBR
60” Ignition Wire (2” per use)
O-Ring 5/16 ID NBR
Adapter, Bomb Cap
O-Ring, FKM 5/64 ID x 1/16CS
Item Complete Assemblies
A1450DD
A1450DDCL
A890DD2
A890DD2CL
Oxygen Bomb Head Assembly
Oxygen Bomb Head Assembly for Chlorine Service
Cylinder Assembly
Cylinder Assembly for Chlorine Service
