PARTS LIST
Principal Assemblies in Calorimeter
Item Description
1138/1138CL
1795E
1796E
897E
A1250DD
A1251DD
A1447DD
A1448DD
A1449DD
A1254DDEB
A1254DDEE
A1255DD
1433DD
A1449DD
A1456DD
A1275DDEB
A1275DDEE
139E23 Oxygen Combustion Vessel
Power Supply, 24V
Power Supply, 5/12V
Capacitor, Ignition
Controller Assembly
Oxygen Solenoid Assembly
Water Solenoid Assembly
Temp Control Sub-Assy
Water Chiller Assembly
Pump Assembly Circulating 115V
Pump Assembly Circulating 230V
Propeller Assembly, stirrer
Tank, Water (A1435DD / 6400)
Water Chiller Assembly
Rinse Valve Assembly
Cartridge, Heater Assembly, 120V
Cartridge, Heater Assembly, 230V
Fuse Fast/ Act 15 AMP 250V
WARNING: For continued protection against possible hazard, replace
fuses with same type and rating of fuse.
A1250DD Controller Assembly Parts List
Item Description
1217DD
1803E
A1876E
A1792E
A1933E6
A1794E
A1806E Gasket for Display
Backlight, Inverter
Touchscreen LCD w/ cable
Transition Display Board
CPU Board 6400
Input / Output Board
Cable, Backlight Inverter
