Parr Instrument 6400 - Manual (Page 35)

6400
Calorimeter Instruction Manual
5-3
Bucket Min Value: Press this key to access its numeric dialog box to set a minimum bucket
value.
Jacket Plot Symbol: (same as Bucket Plot Symbol, above).
Jacket Min Value: Press this key to access its numeric dialog box to set a minimum jacket
value.
Time Window: Sets the time scale for the X-axis
Time Units: Toggles between minutes and seconds.
Bucket Plot Color: Toggles between:
• Red
• Green
• Yellow
• Blue
• Magenta
• Cyan
• White
• Black
Bucket Max Value: Press this key to access its numeric dialog box to set a maximum
bucket value.
Jacket Plot Color: Toggles between:(same as Bucket Plot Color, above).
Jacket Max Value: Press this key to access its numeric dialog box to set a
maximum jacket value.
Time Minimum: Press this key to access its numeric dialog box to set the least
amount of time for the display.
Time Maximum: Press this key to access its numeric dialog box to set the greatest
amount of time for the display.
Operating Controls Menu
Method of Operation:
Offers an operating mode of either
dynamic or equilibrium. In most cases,
the dynamic mode with its curve
matching capability will save
approximately 3-4 minutes per test and
will produce the same operating
precision as the slower equilibrium
mode.
Reporting Units:
Offers a choice of Btu/lb, cal/g, J/kg, or
MJ/kg for the reporting units. A user
selected set of reporting units may be
chosen by selecting “other”.
