Mx,y,sno,nos,mode,ccode,zip,class,rotation,message - Print Maxicode
Syntax Mx,y,sno,nos,mode,ccode,zip,class,rotation,message
Parameter x = Hori. of left-bottom pos. of barcode (unit: dots).
y = Vert. of left-bottom pos. of barcode (unit: dots).
sno = symbol number, in set of symbols: 1 ~ 8.
nos = number of symbols in set of symbols: 1 ~ 8 sets.
mode = mode of maxicode 2, 3, 4 or 6.
ccode = 3 digits country code.
zip = postal code 9 digits for US style postal code. If there is a 5 digits zip code, 4 zeros
must be padded 6 digits alphanumeric zip code for non-US style postal code.
class = service class, 3 digits numeric.
rotation = rotation of barcode (0 ~ 3)
0) 0° 1) 90° 2) 180° 3) 270°
message = 1 ~ 84 characters.
Description Print a 2 dimensional Maxicode
Px,y,w,h,r,c,ec,len,rotation - Print PDF 417
Syntax Px,y,w,h,r,c,ec,len,rotation
Data
Parameters x = Hori. of left-bottom pos. of barcode ( unit: dots)
y = Vert. of left-bottom pos. of barcode (unit: dots)
w = Width (x dimension) of the narrowest element (bar or space) in the barcode.
h = Height (y dimension) of each barcode row in the symbol.
r = number of barcode rows, from 3 to 90. If you key in 0, printer will count all the rows.
c = number of barcode columns, from 1 ~ 30. If you key in 0, printer will count the all
columns.
ec = error correction level: 0 ~ 8.
len = number of encoded data bytes, including carriage returns ↵ and line feed.
rotation = rotation of barcode (0 ~ 3)
0) 0° 1) 90° 2) 180° 3) 270°
Data = data to be encoded (the length of the data must be equal to the set value
of "len"; up to 1024 characters)
Description Print a 2 dimensional PDF417 code
