Upgrading The Computer
Upgrading the Hard Disk Drive 6 - 5
6
3. Remove the hard disk bay cover .
4. Remove screws - from the hard disk assembly.
5. Remove the hard disk assembly by pulling the tab to disconnect it from the
connector .
3
4 9
10
3
4 5 6
7 8 9
10
Figure 6 - 3
Bay Cover Removal
& Hard Disk
Assembly Screws
