Service - 170
JT20 Operator’s Manual
50 Hour
CMW
®
Lube Rotation Gearbox Sliding Output
Shaft
Lube rotation gearbox sliding output shaft with
EPS every 50 hours.
To lube:
• Stop engine and turn battery disconnect
switch to the OFF position.
• Clean exposed portion of sliding output shaft
with pressure washer to remove grime.
• Blow dry with compressed air.
• Apply EPS spray lube to all exposed shaft
surfaces while manually moving the shaft in
and out.
• Turn battery disconnect switch to the ON position.
Inspect Thrust Rollers
Inspect thrust rollers (at each end of carriage)
every 50 hours. Clean or replace if they do not
turn freely.
j38om025w.eps
j38om023w.eps
