Conduct a Bore - 106
JT20 Operator’s Manual
Remove Pipe
CMW
®
9. Load pipe into pipe box:
10. Attach saver sub to next pipe:
• Move carriage forward until saver sub touches pipe.
• Rotate spindle just enough to allow saver sub to connect to pipe.
• Slowly tighten joint to full machine torque.
11. Disengage front wrench to release pipe.
Manual Pipeloader Controls Automated Pipeloader Control
• Move shuttle under pipe box to shuttle
stop.
• Release grippers and raise lift arms to
place pipe in box.
• Lube front threads.
• Press RESUME. Green control cycle light
will come on.
• Shuttles will retract under edge of pipe box
and then green control cycle light will
flash.
• Move carriage forward until it clears end of
pipe box. Green control cycle light will
come on, shuttles will retract, front threads
will be lubed, grippers will release pipe,
pipe lifters will raise until pipe is off
shuttles, and then green control cycle light
will flash.
