Table of Contents
Parts List, Schematics and Diagrams 3 - 15
SL 900 Machine Mounting Assembly 4
Upper Machine Assembly 5
Shot Container Assembly 6
Casefeeder Assembly & Parts List 7
Casefeeder Bowl Mount & Casefeed Assembly to Frame 8
Lower Machine Assembly 9
Toolhead Assembly 10
Platform Assembly 11
Primer Feed System Assembly 12
Automatic Powder Measure Assembly 13
Shot Dispenser Assembly 14
Wad Swing Arm Assembly 15
Finished Shotshell Dimensions 15
General Machine Information 16 - 17
Step-by-Step Preliminary Assembly 17 - 21
Factory Settings 22 - 23
Filling the Machine with Components – What’s First? 24 - 29
Changes and Adjustments 29 - 35
Adjusting the Collet Sizer 29
Powder Die/Funnel Adjustments 30
Adjusting the Automatic Powder System, Powder Charge Weight 30
Adjusting the Wad and Shot Station 30
Adjusting the Starter Crimp Die 31
Removing the Shot From the Machine 31
Removing the Toolhead 32
Shellplate Removal 33
Switching to Another Powder 34
The Primer System 35
Gauge Conversion - 28 ga. 36 - 40
Gauge Conversion - 20 ga. 41 - 45
Troubleshooting Section 46 - 47
Primer System 46
Casefeeder 47
General 47
Lube Points 48
Suggested Settings 49
