Page 86
74
Dolby
®
DP570 Multichannel Audio Tool User’s Manual
Connector Specifications
Stereo/Mono/Solo Analog Output
B.11 Stereo/Mono/Solo Analog Output
This is a 25‐pin female D‐connector.
B.12 GPI/O Connector
For details of the
GPI/O
Assigning GPI/O Functions to Specific Pins
5
Rs Ground
18
Ls + Out
6
Ls – Out
19
Ls Ground
7
Subwoofer +
Out
20
Subwoofer – Out
8
SW Ground
21
Center + Out
9
Center – Out
22
C Ground
10
Right + Out
23
Right – Out
11
R Ground
24
Left + Out
12
Left – Out
25
L Ground
13
No Connection
Table B-6 Stereo/Mono/Solo Analog Output Pinout
Pin
Connection
Pin
Connection
1
Digital Ground
14
NC
2
NC
15
NC
3
NC
16
NC
4
NC
17
NC
5
NC
18
Solo In R +
6
Solo In R –
19
SR Ground
7
Solo In L +
20
Solo In L –
8
SL Ground
21
Mono + Out
9
Mono – Out
22
M Ground
10
Right Stereo + Out
23
Right Stereo – Out
11
R Ground
24
Left Stereo + Out
12
Left Stereo – Out
25
L Ground
13
NC
Table B-5 Multichannel Analog Output Pinout
Pin
Connection
Pin
Connection
