Getting Started Installing the Remote Software
Dolby ® DP570 Multichannel Audio Tool User’s Manual 9
To end remote operation and resume using the front‐panel interface, press Shift then
again.
2.4.6 Starting the Remote Software
To start the remote software:
1. Double‐click the program icon.
2. Review the communication settings, and modify them if necessary.
3. Click OK.
The DP570 alerts you that it is opening the device and, when communication is established,
displays the main application screen shown in Figure 4‐1.
2.4.7 Configure the Setup Monitor Tab
Before the DP570 can begin service you must configure it to reflect your monitoring system.
1. Click Setup on the application button bar. The system opens the Monitor tab shown in
Figure 2‐1.
2. Check the appropriate settings.
For a detailed discussion of the concepts and procedures for setting up a monitoring
system, see
Configuring a Monitor System on page 61.
Your DP570 is now ready to use.
