Driver Installation 83
cPCI-3970
6 Driver Installation
The cPCI-3970 drivers are available from the ADLINK All-In-One
DVD at X:\cPCI\cPCI-3970\, or from the ADLINK website
(http://www.adlinktech.com). ADLINK provides validated driv-
ers for Windows XP Professional and Windows 7. We recommend
using these drivers to ensure compatibility. The VxWorks BSP can
be downloaded from the cPCI-3970 product page on the ADLINK
website
6.1 cPCI-3970 Drivers
The following describes the cPCI-3970 driver installation proce-
dures for Windows XP.
1. Install the Windows operating system before installing any
driver. Most standard I/O device drivers are installed during
Windows installation.
2. Install the chipset driver by extracting and running the pro-
gram in ...\Chipset\Intel_Chipset_Device_Software
_AllOS_9.2.0.1015.zip.
3. Install the Microsoft .NET Framework utilities (required for the
graphics utility) by extracting and running the program in
...\Chipset\Microsoft_Net_Framework_v3.5_SP1.zip.
4. Install the graphics driver and utilities by extracting and run-
ning the program in ...\Graphics\Intel_HD_Graphics
_Family_WinXP_6.14.10.5313.zip.
5. Install the LAN drivers by extracting and running the program
in …\LAN\Intel_82574L_Gigabit_Network_WINXP
_11.4.7.0.zip.
6. Install the Intel Rapid Storage Technology Utility by extract-
ing and running the program in …\AHCI\
Intel_Rapid_Storage_Technology_10.1.0.1008.zip.
7. Install the TPM driver by extracting and running the program in
…\TPM\Infineon_Trusted_Platform_Module_2.1.1.0.zip.
NOTE: NOTE:
In order to enable AHCI mode, you must pre-install the Intel®
Rapid Storage Technology driver using the F6 installation
method described in
…\AHCI\F6Readme.txt.
