Specifications

1. When using the cPCI-R3P00 RTM, LAN1/2 from the 82574L controllers

can be routed via J2 to the RTM. When using the cPCI-R3P00T RTM,
the cPCI-3970 front panel GbE ports change to LAN3/4 and the
cPCI-R3P00T GbE ports are LAN1/2 due to PCI-Express root port
sequence requirements of the PCH.

2. The storage device limits the operational vibration tolerance.

When the application requires higher specification for
anti-vibration, it is recommended to use a flash storage device.

3. ADLINK-certified thermal design. The thermal performance is depen-

dent on the chassis cooling design. Sufficient forced air-flow is required
(see “Thermal Requirements” on page 22). Temperature limits of
optional mass storage devices may also affect the thermal specification.

4. A DB-9-to-DB-9 dongle to convert the cPCI-3970G RS-422/485 pin defi-

nitions to common pin definitions is included in the package
(“cPCI-3970G/U Serial Ports” on page 44).

Faceplate I/O

12HP (cPCI-3970U)
• 2x DisplayPorts
• 3x USB 2.0 ports
• 2x 10/100/1000BASE-T Ethernet ports
• Analog DB-15 VGA port
• RJ-45 RS-232/422/485 port

• PS/2 Keyboard/ Mouse combo port
• PMC/XMC site

Table 2-1: cPCI-3970 Processor Blade Specifications
