138 IPMI User Guide
9.6 IPMI Sensors List
Sensor
Number
Sensor name
Normal
Reading
Sensor Reading Value of
IPMI Get Sensor Reading
Command
01h BMC Watchdog
Timeout action:
000b = no action
001b = Hard Reset
000b = Power Down
011b = Power Cycle
100b - 111b = reserved
02h 3.3V 3.3 V Raw data of 3.3V sensor
03h 5V 5 V Raw data of 5.0V sensor
04h 12V 12 V Raw data of 12.0V sensor
05h CPU Temp 40ºC Raw data of CPU Temp sensor
06h SYSTEM Temp 25ºC
Raw data of SYSTEM Temp
sensor
07h +1.8V 1.8V Raw data of 1.8V sensor
08h +1.5V 1.5V Raw data of 1.5V sensor
09h CORE V 0.3V~1.52V Raw data of P_VCORE sensor
0Ah VCC GFX 0V~1.52V Raw data of VCC_GFX sensor
0Bh CPU +1.05V 1.05V
Raw data of P1V05_CPU
sensor
0Ch PCH +1.05V 1.05V
Raw data of P1V05_PCH
sensor
0Dh VCCSA 0.75V~0.95V Raw data of VCCSA sensor
0Eh +0.75V 0.75V Raw data of P0V75 sensor
0Fh System power OK N/A
Status:
00b : Power Fail
01b : Power OK
