Specifications

19

cPCI-3970

2.4

I/O Connectivity Table

1. Switched from front ports for cPCI-R3P00, ports independent from

front panel for cPCI-R3P00T.

2. Switched from front port.

Function

cPCI-3970

(4HP)

cPCI-3970D

(8HP)

cPCI-3970G

(8HP)

R3P00(T)

(RTM)

Faceplate Onboard Faceplate Onboard Faceplate Onboard Faceplate Onboard

Gigabit
Ethernet

Y x2

Y x2

Y x2

Y x2

1

COM

Y

(DB-9)

Y

(RJ-45)

Y

(10-pin)

Y x2

USB 2.0

Y x2

Y x4

Y x3

Y x2

VGA

Y

Y

Y

Y

2

DisplayPort

Y x2

Serial ATA

Y (2.5"

HDD)

Y (2.5"

HDD)

Y x3

(7-pin)

CF/CFast

Y

Y

Y

PS/2
KB/MS

Y

Y

Line-in/out

Y

System
LEDs

Y x5

Y x5

Y x5

Reset
Button

Y

Y

Y
