IPMI User Guide 135
cPCI-3970
Thermal Detection
This command is used to get temperatures from external sensor
components.
Voltage Detection from External Sensor
This command is used to get voltages from external sensor com-
ponents.
Action Byte Value Description
Request
0 18h NetFn/LUN
1 59h Defined command
2 01h~02h
01h : CPU Temperature
02h : System Temperature
Response
0 Complete Code 00h means OK
1:2
Assigned
Temperature value
from Request
It gets digital raw data. The
practical value can be
translated by formula.
Action Byte Value Description
Request
0 18h NetFn/LUN
1 5Ah Defined command
2 01h~08h
01 : +1.8V
02 : +1.5V
03 : CORE V
04 : VCC GFX
05 : CPU +1.05V
06 : PCH +1.05V
07 : VCCSA
08 : +0.75V
Response
0 Complete Code 00h means OK
1:2
Assigned Voltage
value from Request
It gets digital raw data. The
practical value can be
translated by formula.
