ADLINK cPCI-3970 Series User Manual
Page 23
Specifications
9
cPCI-3970
Faceplate I/O
4HP (cPCI-3970) & 8HP (cPCI-3970Q)
• 2x USB 2.0 ports
• 2x 10/100/1000BASE-T Ethernet ports
• Analog DB-15 VGA port
8HP (cPCI-3970D)
• 4x USB 2.0 ports
• 2x 10/100/1000BASE-T Ethernet ports
• Analog DB-15 VGA port
• DB-9 RS-232/422/485/485+ port
• PS/2 Keyboard/ Mouse combo port
• Line-in and Line-out port
8HP (cPCI-3970G)
• 2x DisplayPort
• 3x USB 2.0 ports
• 2x 10/100/1000BASE-T Ethernet ports
• Analog DB-15 VGA port
• RJ-45 RS-232/422/485 port
2
• PS/2 Keyboard/ Mouse combo port
8HP (cPCI-3970L)
• 3xUSB 2.0 ports
• 4x 10/100/1000BASE-T Ethernet ports
• Analog DB-15 VGA port
• DB-9 RS-232/422/485 port
• USB port
8HP (cPCI-3970M)
• 2xUSB 2.0 ports
• 2x 10/100/1000BASE-T Ethernet ports
• Analog DB-15 VGA port
• 100-pin I/O port for Line-in, Line-out, 2x DVI, 2xUSB,
2x RS-232/422/485, KB/MS
12HP (cPCI-3970P)
• 4x USB 2.0 ports
• 2x 10/100/1000BASE-T Ethernet ports
• Analog DB-15 VGA port
• DB-9 RS-232/422/485/485+ port
• PS/2 Keyboard/ Mouse combo port
• Line-in and Line-out port
• PMC/XMC site
Table 2-1: cPCI-3970 Processor Blade Specifications
