Specifications 7
cPCI-3970
2 Specifications
2.1 cPCI-3970 Processor Blade Specifications
CompactPCI®
Standards • PICMG® 2.0 CompactPCI® Rev. 3.0
• PICMG® 2.1 Hot Swap Specification Rev. 2.0
• PICMG® 2.9 System Management Rev. 1.0
• PICMG® 2.30 PlusIO compatible (cPCI-3971 supports full
PICMG 2.30 compliance - UHM type J2 connector)
Mechanical • Standard 3U CompactPCI®
• Board size: 100mm x 160mm
• Single slot (4HP, 20.32mm); Dual slot (8HP, 40.64mm);
Triple-slot (12HP, 60.96 mm)
• CompactPCI® connectors with J1, J2; HM type J2 connector
for cPCI-3970 models, UHM type J2 connector for cPCI-3971
Processor • Intel® Core™ i7-2715QE Processor, 2.1 GHz, 6MB LLC,
FCBGA1023, TDP 45W
• Intel® Core™ i7-2655LE Processor, 2.2 GHz, 4MB LLC,
FCBGA1023, TDP 25W
• Intel® Core™ i7-2610UE Processor, 1.5 GHz, 4MB LLC,
FCBGA1023, TDP 17W
• Intel® Core™ i5-2515E Processor, 2.5 GHz, 3MB LLC,
FCBGA1023, TDP 35W
• Passive heatsink
Chipset • IIntel® QM67 Platform Controller Hub (PCH)
Memory • Dual channel DDR3-1066/1333 ECC memory
• Two SO-CDIMM sockets
• Up to 16GB (dependent on availability of memory modules)
CompactPCI
Bus • PCI 32bit/ 33MHz; 3.3V, 5V universal V I/O
• Supports operation in system slot as master or in peripheral
slot as standalone blade without connectivity to CompactPCI
bus (Satellite mode)
Gigabit
Ethernet • Two PCI-Express x1 Intel® 82574L Gigabit Ethernet
controllers
• Two egress 10/100/1000BASE-T ports switchable to J2
(cPCI-R3P00) by BIOS setting
1
Serial Ports • Up to four serial ports
• One RS-232/422/485 serial port on front panel
• Additional RS-232 10-pin header on layer-2 board
(cPCI-3970G only)
• Two serial ports on RTM
Table 2-1: cPCI-3970 Processor Blade Specifications
