134 IPMI User Guide
Voltage Detection from Internal Sensor
This command is used to get voltages from internal sensor com-
ponents
.
Response
0 Complete Code 00h means OK
1:2
Reset Times
on Power Button
The counter is added byt
pushing reset button. LS
byte last.
3:4
Reset Times
on Payload
The counter is added by
system reset request on
payload. LS byte last.
5:6
Reset Times
on WDT
The counter is added by
Watch Dog Timer function.
LS byte last.
7:8
Reset Times
on other cause
The counter is added by
other causes. For example :
cold reset. LS byte last.
9 Last Reset Cause
It records the latest cause of
triggering reset behavior.
Action Byte Value Description
Request
0 18h NetFn/LUN
1 58h Defined command
2 01h~03h
01h : +3.3V MAIN
02h : +5.0V MAIN
03h : +12.0V MAIN
Response
0 Complete Code 00h means OK
1:2
Assigned Voltage
value from
Request
It gets digital raw data. The
practical value can be translated
by formula.
Action Byte Value Description
