8 Specifications
Graphics • Integrated in Intel® Core™ processor
• DB-15 VGA port on front panel, switchable to J2 (RTM) by
BIOS setting
• Analog display up to QXGA 2048x1536 @75Hz, 32-bit
• Two DisplayPorts on front panel with resolution up to
2560x1600 @60Hz (cPCI-3970G/U only)
• Dual independent display
USB • Up to four USB 2.0 front panel ports, 3 USB 2.0 ports to J2
(RTM)
PMC/XMC • One 32-bit/66MHz PMC site or PCIe x1 XMC site if
DB-3UMC riser card is installed
Audio • One Line-in and one Line-out port on front panel
(cPCI-3970D only)
TPM Infineon SLB 9635 TT1.2 ( not available on Ext. Temp. version )
• Over/Under voltage detection
• Low/High frequency sensor/filter
• Reset filter
• Memory Encryption/Decryption
Storage
Interface
2
• CompactFlash Type I or II socket on riser card
• Optional CFast Type I or II socket on riser card
(shares site with CF)
• One SATA 6Gb/s direct connector for 2.5" onboard HDD/SDD
(8HP/12HP version only)
BIOS • AMI® EFI BIOS, 64Mbit SPI flash memory
OS
Compatibility • Microsoft Windows XP Professional
• Microsoft Windows 7 64-bit
• Red Hat Enterprise Linux 6 64-bit
• Fedora 14 32-bit
• Other OS support upon request
Environmental • Operating Temperature (with forced air flow)
3
:
Standard: 0°C to 60°C
Extended Temperature: -20°C to 70°C (for Intel® Core™
i7-2655LE, i7-2610UE processors only, with forced air flow)
• Storage Temperature: -40°C to 85°C
• Humidity: 95% @60°C non-condensing
• Shock: 15G peak-to-peak, 11ms duration, non-operating
• Vibration
2
: 2Grms, 5-500Hz, each axis, operating (w/o hard
drive)
EMI • CE EN55022
• FCC Class A
Table 2-1: cPCI-3970 Processor Blade Specifications
