Introduction
X
VGA port on front or switchable to rear I/O by BIOS setting
X
Two PCIe Gigabit Ethernet egress ports
X
Additional two Gigabit Ethernet ports on 80mm RTM
(cPCI-R3P00T)
X
One CompactFlash socket
X
Optional CFast socket for SATA interface storage (shares CF
socket site)
X
Line-in and Line-out ports on front panel
X
2.5" SATA drive onboard on 8HP/12HP versions at 6 Gb/s
1.3
Model Number Decoder
Blades
(A) Operating Temperature Code
Z
Blank = 0ºC to +60ºC
Z
ET = -20ºC to +70ºC (for CPUs with TDP below 25W only)
(B) J2 Connector Type Code
Z
0 = HM connector
Z
1 = UHM connector (PICMG 2.30 PlusIO compliant)
(C) Configuration Code
Z
Blank = Single slot width with CF socket, 2x USB, 2x GbE,
VGA
Z
D = Dual slot width with CF socket, 2x USB, 2x GbE, VGA
on layer-1; 2x USB, COM, PS/2 KB/MS, Line-in, Line-out
and SATA on layer-2 DB-3610L2
Z
G = Dual slot width with CF socket, 2x USB, 2x GbE, VGA
on layer-1, 2x DisplayPort, RJ-45 COM, PS/2 KB/MS, USB
and SATA on layer-2 DB-3970L2
cPCI-
ET
397
0 D
/
655L
/
M4G
(A)
(B)(C)
(D)
(E)
