Operation Theory

63

4.2.11 Home Search Function

This mode is used to add auto searching function on normal home
return mode described in previous section no matter which posi-
tion the axis is. The following diagram shows an example for home
mode 2 via home search function. The ORG offset can’t be zero.
The suggested value is the double length of ORG area.
