MotionCreatorPro 97
7. Operation Mode: Select operation mode.
Z
Absolute Mode: “Position1” and “position2” will be used
as absolution target positions for motion. The related
functions are _8158_start_ta_move(),
_8158_start_sa_move().
Z
Relative Mode: “Distance” will be used as relative dis-
placement for motion. The related function is
_8158_start_tr_move(), _8158_start_sr_move().
Z Cont. Move: Velocity motion mode. The related function
is _8158_tv_move(), _8158_start_sv_move().
Z
Manual Pulse Move: Manual Pulse motion. Clicking this
button will invoke the manual pulse configuration win-
dow.
Z
Home Mode: Home return motion. Clicking this button
will invoke the home move configuration window. The
related function is _8158_set_home_config().If the
