6. To remove the inner plate, pullthe plate outandthen up.

C. Reassemblyof Air Fingers

SECTION 4

MAINTENANCE

Figure 4-11.

7. The outer finger plate is stainless and may be cleaned

by either soaking in a hot, strong detergent solution or
using a caustic cleaner. The conveyor belt can also be

cleaned in the same way.

Figure 4-12. Standard Lower Finger

1. Air fingers are made up of one Inner plate, one outer

plate and the finger housing manifold. Be sure to match up

the markings

m. T2. T3. etc.^ on all the parts of the air

fingers as you are reassembling.

Figure 4-14.

2.

Reassembletheinnerpiate.Keepyourflngersclearso

you won’t pinch them. The inner plate of a finger will only
go in one way because of Its design.

3. Replace the outer plate by placing your hands flat on
the top of the plate and pushing down. Keep your fingers
clear so you won’t pinch them.
