7
2.2 Equipment Class
Type A: Equipment that is intended for connection to the building power supply wiring via nonindustrial plugs and
sockets or via appliance couplers, or both.
2.3
Disposal and Recycling
Wheelie‐Bin Symbol
The Wheelie‐Bin symbol is attached to this product in compliance with the EU Directive 2002/96/EC on
Waste Electrical and Electronic Equipment (WEEE). Its purpose is to deter the improper disposal of this
product and to promote reuse and recycling.
Proper Disposal
In conformance with the Directive, at end of life this product should be either sent to an appropriate recycling
facility for disassembly and recycling or returned to the supplier. Under no circumstances should this product be
deposited in a landfill for disposal.
Hazards of Noncompliance
Electrical and electronic products may contain chemicals which can leach into the groundwater and cause health
concerns through contaminated drinking water. Failure to dispose of this product in compliance with the WEEE
Directive may result in penalties as determined by local ordinance.
Please contact your dealer or USL, Inc., with questions regarding the proper disposal of this or any other USL
product. USL, Inc. contact information: USL, Inc., 181 Bonetti Drive, San Luis Obispo, CA 93401‐7397, USA.
Phone: +1 805 549 0161 Fax: +1 805 549 0163
www.uslinc.com
3.
System Version
The JSD‐100 is continuously being improved. New features are added through software/firmware updates and
replacement of plug‐in modules. This manual describes the JSD‐100 versions available at this writing.
Firmware/software versions for the systems described in this manual are listed in the table below:
4. System Overview
4.1
System Description
The JSD‐100 cinema sound processor is specially designed for digital cinema applications. Low noise and low
distortion 96 kHz processing ensures superb presentations. In addition to the eight standard formats, the JSD‐100
offers two fully configurable formats. The two user‐configurable buttons can be configured to support a variety of
existing and future formats. They may also be used to duplicate an existing format but at a different fader level to
simplify desired volume changes between content types. The front panel display shows the current fader level, the
format name (which is user configurable), and the measured audio level on each channel of the main audio output.
The built‐in bypass audio circuitry insures that the presentation goes on in the unlikely event of a system failure.
The JSD‐100 is “automation friendly.” It features the standard DB25 parallel automation interface, an RS‐232
(EIA232) interface, and Ethernet. The Ethernet interface accepts 5 simultaneous TCP connections to allow control
by a digital cinema server and other equipment while simultaneously being monitored over another TCP
connection.
Component Version
Graphical User Interface (GUI) 2.3.5.27222
Main PIC 110929
DSP 1 1110819
DSP 2 2110819
