42
Full Range
Cable Pair 5.1
7.1 DS 7.1 SDDS 13.1
1‐1 L/R L/R L/R L/R
1‐2 C/LFE1 C/LFE1 C/LFE1 C/LFE1
1‐3 Ls/Rs Ls/Rs Ls/Rs Ls/Rs
1‐4 Not Used Lrs/Rrs Lc/Rc Lc/Rc
3‐1 Not Used Not Used Not Used OUT 9/10
3‐2 Not Used Not Used Not Used OUT 13/14
3‐3 Not Used Not Used Not Used LFE2/LFE3
3‐4 Not Used Not Used Not Used Lrs/Rrs
Biamp
Cable Pair 5.1 Biamp 7.1 DS Biamp 7.1 SDDS Biamp 13.1 Biamp
1‐1 Cm/Ch (Cm not used) Cm/Ch (Cm not used) Cm/Ch (Cm not used) Cm/Ch (Cm not used)
1‐2 Cl/LFE1 Cl/ LFE1 Cl/ LFE1 Cl/ LFE1
1‐3 Ll/Rl Ll/Rl Ll/Rl Ll/Rl
1‐4 Lh/Rh Lh/Rh Lh/Rh Lh/Rh
2‐1 LCl/RCl LCl/RCl LCl/RCl LCl/RCl
2‐2 LCh/RCh LCh/RCh LCh/Rch LCh/RCh
2‐3 Ls/Rs Ls/Rs Ls/Rs Ls/Rs
2‐4 Not Used Lrs/Rrs Lrs/Rrs Lrs/Rrs
3‐1 Not Used Not Used OUT 9/10 OUT 9/10
3‐2 Not Used Not Used OUT 13/14 OUT 13/14
3‐3 Not Used Not Used LFE2/LFE3 LFE2/LFE3
3‐4 Not Used Not Used Lrs/Rrs Lrs/Rrs
Triamp
Cable Pair 5.1 Triamp 7.1 DS Triamp 7.1 SDDS Triamp 13.1 Triamp
1‐1 Cm/Ch Cm/Ch Cm/Ch Cm/Ch
1‐2 Cl/LFE1 Cl/LFE1 Cl/LFE1 Cl/LFE1
1‐3 Ls/Rs Ls/Rs Ls/Rs Ls/Rs
1‐4 (Not Used) Lrs/Rrs Lh/Rh Lrs/Rrs
2‐1 Ll/Rl Ll/Rl Ll/Rl Ll/Rl
2‐2 Lm/Rm Lm/Rm Lm/Rm Lm/Rm
2‐3 Lh/Rh Lh/Rh Lh/Rh Lh/Rh
2‐4 Ls1/Rs1 Ls1/Rs1 LFE2/LFE3 Ls1/Rs1
3‐1 Not Used Not Used Not Used OUT 9/10
3‐2 Not Used Not Used Not Used OUT 13/14
3‐3 Not Used Not Used Not Used LFE2/LFE3
3‐4 Not Used Not Used Not Used LFE4
4‐1 Not Used Not Used LCl/RCl LCl/RCl
4‐2 Not Used Not Used LCm/RCm LCm/RCm
4‐3 Not Used Not Used LCh/RCh LCh/RCh
4‐4 Not Used Not Used Ls1/Rs1 Ls1/Rs1
