background image

36

www.teejet.com

Fieldware

®

Tools

QUICK START

Select Form a Sampling Pattern from the Program Launcher Tools menu, or double click

on the Form a Sampling Pattern icon in the Windows Explorer. The Receiver Process is not

required for this program.
From the Main menu in the Setup page, enter the appropriate Client, Farm and Field

information. For fast entry you may select the default Client, Farm, Field information that is

presented. Save this information in a Setup file.
Enter a background file name in the Background file menu field. Typically this is the

boundary file (.BND) for the field that you are creating a sampling pattern for.
Enter the output file name in the Output File menu field. The grid and associated point

positions will be stored in this file.
Move to the Grid Menu page by pressing the GRID tab.
Store Grid menu field, enter YES if you want the final grid stored in the output data file.

Enter NO if you do not want to store the grid.
Store Points menu field, enter YES if you want to store the sample points in the output file.

Enter NO if you do not want to store any points
Select the type of point sampling pattern.
Enter the grid cell size, either by area or height and width.
To save this information in the Setup file, press the SAVE button. To continue to the next

step press the NEXT button.
Orient the sampling grid using the rotation buttons and the shifting arrows.
Once the sampling grid is in the desired rotation, press the NEXT button to move to the

Sample points page.
In the Sample Points page, edit, add, or delete any points. Once satisfied with sampling

pattern press the FINISH button.
