The View Menu
The View menu sets up the Map Manager window (Table 4).
Figure 10: The View Menu
Figure 11: The View Options Dialog
Table 4: The View Menu Item Descriptions
Menu Item View Menu Item Description
Tool Bar Places or removes the Tool bar from the Map Manager window.
Status Bar
Places or removes the Status bar from the bottom of the Map Manager window and
displays the current action as well as the real world coordinate position of the pointer.
Split Activates the split screen function, allowing you to resize the map view and file tree.
Zoom to Current Zooms to the current layers data extents. This can be accomplished from the tool bar,
see Table 1.
Zoom to Extent
Zooms to the data extents which all visible layers are contained. This can be accomplished
from the tool bar, see Table 1.
Zoom Previous
Returns to the previous zoom state. This can be accomplished from the tool bar,
see Table 1.
Show Tags
Displays a small yellow tag next to each object in the map view. The tag contains
information about the object.
Options
Brings up the Options dialog where the system units and coordinate system can be
changed, see (Figure 11).
Show All Files
When selected the file tree displays all file types. When de-selected, the file tree shows
only Fieldware file types.
