(Optional) Mounting to a Cabinet/Rack
If you wish to mount the SV1107IPEXT in a server/storage rack/cabinet, using the included
bracket:
1. (Figure 1) Remove
the two screws
closest to the rear
panel of the
SV1107IPEXT, on the
base of the unit.
2. (Figure 2) Place the
mounting bracket on
the base, aligning
the circular holes on
the bracket with the
holes left from the
removed screws,
positioning the
bracket as shown.
Then, replace the screws
removed in step #1.
3. Mount the SV1107IPEXT
in the server/storage
rack/cabinet as appropriate:
1
2
3
