Instruction Manual 15
The SV1107IPEXT Main Screen appears:
The Main Screen consists of Administration icons arranged horizontally across the top of the
screen (see pg. 15), and Utility icons arranged vertically on the left side of the screen (described
in table below).
Utility Icons
Apply: Saves the changes you make in the administration dialog boxes,
but does not implement the changes, which go into effect when you
enable Reset on exit (see Customization) and log out.
Windows Client: Allows users with the proper permission to connect
to the SV1107IPEXT using Windows software, to remotely control the
server.
Java Applet: For platform independence, the Java applet allows users
with the proper permission (see User Manager ) and Java installed on the
remote computer, to connect to the SV1107IPEXT and remotely control
the sever.
Log: All the events that take place on the SV1107IPEXT are recorded in a
log file. If you have the proper permission clicking on this Icon displays
the contents of the log file
Note: See the next page for an explanation of the Log utility.
Logout: Click this icon to log out and end your session
Note: It is important to end your session, so the SV1107IPEXT can
terminate the session. If you get a “System in use” error message its
because the session ended with out Logging out, Logon with the other
Client.
Apply
Windows Client
Java
Log Log
Log out
