Instruction Manual 29
Icon Function
Exit from the Windows Client
From left to right, these icons indicate the current
Num Lock, Caps Lock and Scroll Lock state,
respectively.
When the corresponding icon is illuminated, the
function is active. When connected, toggle the
LEDs to set the correct state
Please Note: You can move the control panel to any convenient location on the remote
window’s screen, by clicking on the title bar, and dragging it.
The Windows Client Control Panel icons and their functions are described in the sections that
follow.
Hotkey Setup
Various actions related to manipulating the remote server can be accomplished using hotkeys.
The Hotkey Setup utility (accessed by clicking the Keyboard icon on the Control Panel), lets
you configure which hotkeys perform the actions. The actions are listed in the left panel, the
corresponding hotkeys that invoke them are shown in the panel at the right.
