StarTech.com SV1107IPEXT - Manual (Page 39)

Instruction Manual 35
Show / Hide (User List): When you hide the User List, the User List
panel closes. The button is shadowed when the User List is open
Exit: Click to close the message board
Please Note: Only users who are currently logged on can see the Message Board - it is not visible
on the local monitor.
Virtual Media
The SV1107IPEXT’s Virtual Media feature allows a USB 2.0 device (Floppy drive, or Flash Drive), on
a remote system, to act as if it were installed on the local server.
Please Note: The Virtual Media function is:
Only supported by the Windows Client on computers running Windows 2000 or higher.
Not supported on computers using other operating systems (for example Linux).
Not supported on any computer via the Java Client software.
Connect the (mini B to A) USB cable between the Virtual Media port on the SV1107IPEXT and a
USB port on the local computer.
Connect a USB mass storage device to a USB port on the remote Computer.
