Instruction Manual 26
5. Enable the Reset on Exit checkbox on the Customization page.
6. Re-click the Apply icon at the left of the web page.
7. Click the Logout icon at the upper right of the web page to exit and reset the SV1107IPEXT.
Using the SV1107IPEXT
Start by accessing the unit through your local network, to verify the settings are correct and
operate as desired. Once the setup is confirmed on your local network, the final step will be to
connect through the Internet.
Required Equipment
A networked computer, either on your network or on the Internet, that meets the following
minimum requirements (you cannot use the computer that is directly connected to the
SV1107IPEXT):
• Pentium® III 1 GHz processor or higher
• A screen resolution set to 1024 x 768.
• A browser supporting 128-bit SSL data encryption
• Recommended Internet connection speed: 128 kbps or higher
• For the browser-based Windows Client, you must have DirectX® 7.0 or higher installed.
• For the browser-based Java Applet, you must have Sun’s Java Runtime Environment Version
6 Update 3 or higher
Connecting from your Local Network
1. Ensure the remote computer is connected to your network.
2. Ensure the SV1107IPEXT is connected to your local network.
3. Open a web browser on the remote computer.
4. Type in the IP Address you wrote down in step 6 of SV1107IPEXT Initial configuration for
example http://192.168.1.60, then hit the enter key
5. You will be taken to the SV1107IPEXT Logon screen
6. Enter your user name and password in the spaces provided and click on Logon. This brings
you to the SV1107IPEXT main screen.
