Instruction Manual 17
Network
The Network dialog is used to specify the SV1107IPEXT’s network environment.
Access Ports
If a firewall is being used, the Administrator can specify
(in the firewall set up) the port numbers that it will
allow. When connecting to the SV1107IPEXT, users must
specify the port number as part of the IP Address.
If an invalid port number (or no port number)
is specified, the SV1107IPEXT will not be found.
(i.e 192.168.0.60 / 9000 for the Windows client,
192.168.0.60/9002 for the Java client.)
Please Note:
If there is no firewall (on an Intranet, for example),
these numbers will not have any effect.
The access ports cannot have the same value.
A different value must be set for each one.
Explanations of the fields are given in the table below:
Field Explanation
Program
This is the port number that must be specified when connecting
from the Administrator and Windows Client. Valid entries are
between 1024 -60,000
