Instruction Manual 16
Administration
The icons arranged vertically on the left side of the screen (shown left) are linked to the
administration utilities, which are used to configure the SV1107IPEXT.
Your ability to make configuration changes depends on the permissions associated with your
login information.
Once you login, the General panel displays on the browser window shown below). It is the first of
the Administration pages, and provides information about the SV1107IPEXT’s status.
An explanation of each of the fields is given in the following table:
Field Explanation
Device
Name:
To make it easier to manage installations that have more than one
SV1107IPEXT, each one can be given a unique name. Assign a name
(up to 16 characters) by entering it here.
MAC
Address:
Displays the SV1107IPEXT’s MAC Address.
Firmware
Version:
Indicates the SV1107IPEXT’s current firmware version level.
