Instruction Manual 12
Hardware Setup
Installation
To install the SV1107IPEXT, refer to the installation diagram on the following
page:
1. Use the Console cable provided to connect the SV1107IPEXT’s Console port, to the local
keyboard, monitor and mouse, they are color coded for identification.
2. Use the KVM cable provided to connect the SV1107IPEXT’s PC/KVM port, to the video and a
USB port on the computer.
3. Connect your network cable between the SV1107IPEXT’s LAN port and your router.
4. Connect your computer to the network.
5. Connect the mini B to A -USB connector between SV1107IPEXT Virtual Media port and a USB
port on your computer.
6. Connect the power adapter cable to the SV1107IPEXT’s power jack
Please Note: Both the SV1107IPEXT and your computer must be connected to your router. If you
are using a wireless network , switch to a wired connection to set up the SV1107IPEXT, once you
know everything is working you can switch back to wireless
Please Note: The SV1107IPEXT to router connection must be wired.
Warning!
Please ensure that power has been removed from all devices that will be connected during the
installation. You must unplug the power cords of any computers that support Keyboard Power
On function.
