Instruction Manual 34
Enable / Disable (Chat): When disabled, messages posted to the
board are not displayed. The button is shadowed when Chat is
disabled. The Icon displays next to the user’s name in the User List
panel when Chat has been disabled.
Occupy / Release (Keyboard / Video / Mouse): When you Occupy
the SV1107IPEXT, other users cannot see the video, nor can they input
keyboard or mouse data. The button is shadowed when the unit is
occupied.
The icon displays next to the user’s name in the User List panel when
they have occupied the SV1107IPEXT
Occupy / Release (Keyboard / Mouse): When you Occupy the
SV1107IPEXT, other users can see the video, but cannot input
keyboard or mouse data. The button is shadowed when the unit is
occupied. The icon displays next to the user’s name in the User List
panel when they occupy the SV1107IPEXT
User List Panel
Currently logged in users are listed in this panel.
• Your name appears in blue, the other users’ name appears in black.
• By default, messages are posted to all users. To post a message to an individual user, select
the user’s name before sending your message.
• If a user’s name is selected, and you want to post a message to all users, select All Users prior
to sending a message.
• If a user has disabled Chat, an icon is shown by the user’s name to indicate as such
• If a user has occupied the KVM or the KM, its icon displays by the user’s name to indicate so.
