About This Chapter
9/24/01 5-1
Chapter 5
Electrical Installation
Contents of This Chapter:
5.1 About This Chapter
This chapter describes how to install the communication interface and power connectors on the
Access Bank II SNMP Control Panel and includes procedures for:
• Enabling the internal lithium battery.
• Connecting the voice circuits to the punch-down block.
• Connecting the T1 lines.
• Connecting the RS-232 Management Port.
• Connecting the V.35 DCE data port.
• Using Adapters.
• Connecting the Power and Ground.
• Bringing the Access Bank II SNMP on line.
About This Chapter .................................... 1
.Installing Cables and Adapters ................. 2
Interface and Power Connectors ............... 4
Connecting the Voice Circuits .................... 5
Connecting the Dual T1 Lines ................... 6
V.35 DCE Data Port Connections .............. 7
RS-232 Management ............................... 12
Connecting the Power and Ground ......... 15
