Reznor ADFH Parts Manuals - Manual (Page 9)

Form P-ADF, P/N 270068 R1, Page 9
CODE 45 - Motor
CODE 50 - Starter Contactor with line voltage coil
and Overloads (used on units mfgd prior to 9/03)
Type HP P/N volt ph Mfg No. P/N min max GE # P/N
OPEN
1/2
102627 120 1 CL00A310T-J 151146 8.00 12.00 RTA1-N 151193
OPEN 102627 208 1 CL00A310T-L 151150 4.00 6.30 RTA1-L 151191
OPEN 102627 240 1 CL00A310T-S 151147 4.00 6.30 RTA1-L 151191
OPEN 159183 208 3 CL00A310T-L 151150 1.90 2.70 RTA1-J 151189
OPEN 159183 240 3 CL00A310T-S 151147 2.50 4.10 RTA1-K 151190
OPEN 159183 480 3 CL00A310T-U 151148 1.30 1.90 RTA1-H 151188
OPEN
3/4
93548 120 1 CL01A310T-J 151151 10.00 16.00 RTA1-P 151194
OPEN 93548 208 1 CL00A310T-L 151150 5.50 8.50 RTA1-M 151192
OPEN 93548 240 1 CL00A310T-S 151147 4.00 6.30 RTA1-L 151191
OPEN 36951 208 3 CL00A310T-L 151150 2.50 4.10 RTA1-K 151190
OPEN 36951 240 3 CL00A310T-S 151147 2.50 4.10 RTA1-K 151190
OPEN 36951 480 3 CL00A310T-U 151148 1.00 1.50 RTA1-G 151187
OPEN
1
13685 120 1 CL01A310T-J 151151 10.00 16.00 RTA1-P 151194
OPEN 13685 208 1 CL00A310T-L 151150 5.50 8.50 RTA1-M 151192
OPEN 13685 240 1 CL00A310T-S 151147 5.50 8.50 RTA1-M 151192
OPEN 36580 208 3 CL00A310T-L 151150 2.50 4.10 RTA1-K 151190
OPEN 36580 240 3 CL00A310T-S 151147 2.50 4.10 RTA1-K 151190
OPEN 36580 480 3 CL00A310T-U 151148 1.30 1.90 RTA1-H 151188
OPEN 158175 575 3 CL00A310T-Y 151149 1.00 1.50 RTA1-G 151187
OPEN
1.5
194202 120 1 CL02A310T-J 151156 10.00 16.00 RTA1-P 151194
OPEN 194202 208 1 CL00A310T-L 151150 5.50 8.50 RTA1-M 151192
OPEN 194202 240 1 CL00A310T-S 151147 5.50 8.50 RTA1-M 151192
OPEN 115859 208 3 CL00A310T-L 151150 4.00 6.30 RTA1-L 151191
OPEN 115859 240 3 CL00A310T-S 151147 4.00 6.30 RTA1-L 151191
OPEN 115859 480 3 CL00A310T-U 151148 2.50 4.10 RTA1-K 151190
OPEN 158162 575 3 CL00A310T-Y 151149 1.30 1.90 RTA1-H 151188
OPEN
2
202581 120 1 CL25A310T-J 151160 17.50 22.00 RTA1-T 151197
OPEN 202581 208 1 CL01A310T-L 151155 8.00 12.00 RTA1-N 151193
OPEN 202581 240 1 CL01A310T-S 151152 8.00 12.00 RTA1-N 151193
OPEN 159327 208 3 CL00A310T-L 151150 5.50 8.50 RTA1-M 151192
OPEN 159327 240 3 CL00A310T-S 151147 5.50 8.50 RTA1-M 151192
OPEN 159327 480 3 CL00A310T-U 151148 2.50 4.10 RTA1-K 151190
OPEN 158176 575 3 CL00A310T-Y 151149 1.90 2.70 RTA1-J 151189
OPEN
3
111560 208 1 CL02A310T-L 151159 10.00 16.00 RTA1-P 151194
OPEN 111560 240 1 CL01A310T-S 151152 10.00 16.00 RTA1-P 151194
OPEN 159185 208 3 CL00A310T-L 151150 8.00 12.00 RTA1-N 151193
OPEN 159185 240 3 CL00A310T-S 151147 8.00 12.00 RTA1-N 151193
OPEN 159185 480 3 CL00A310T-U 151148 4.00 6.30 RTA1-L 151191
OPEN 120019 575 3 CL00A310T-Y 151149 2.50 4.10 RTA1-K 151190
OPEN 152002 208 3 ====== ====== 8.00 12.00 RTA1-N 151193
OPEN 152002 240 3 ====== ====== 5.50 8.50 RTA1-M 151192
OPEN 152002 480 3 ====== ====== 2.50 4.10 RTA1-K 151190
OPEN
5
111562 208 1 CL04A310M-L 151169 25.00 32.00 RTA1-V 151199
OPEN 111562 240 1 CL04A310M-S 151166 25.00 32.00 RTA1-V 151199
OPEN 113371 208 3 CL01A310T-L 151155 10.00 16.00 RTA1-P 151194
OPEN 113371 240 3 CL01A310T-S 151152 10.00 16.00 RTA1-P 151194
OPEN 113371 480 3 CL00A310T-U 151148 5.50 8.50 RTA1-M 151192
OPEN 120020 575 3 CL00A310T-Y 151149 4.00 6.30 RTA1-L 151191
OPEN
7.5
105828 208 1 CL06A311M-L 151173 30.00 43.00 RTA2-E 151206
OPEN 105828 240 1 CL45A310M-S 151170 25.00 32.00 RTA1-V 151199
OPEN 105854 208 3 CL25A310T-L 151164 21.00 26.00 RTA1-U 151198
OPEN 105855 240 3 CL25A310T-S 151161 17.50 22.00 RTA1-T 151197
OPEN 105855 480 3 CL01A310T-U 151153 8.00 12.00 RTA1-N 151193
OPEN 158164 575 3 CL00A310T-Y 151149 5.50 8.50 RTA1-M 151192
OPEN
10
105830 208 1 CL06A311M-L 151173 30.00 43.00 RTA2-E 151206
OPEN 105830 240 1 CL06A311M-S 151172 30.00 43.00 RTA2-E 151206
OPEN 105857 208 3 CL04A310M-L 151169 25.00 32.00 RTA1-V 151199
OPEN 105858 240 3 CL04A310M-S 151166 25.00 32.00 RTA1-V 151199
OPEN 105858 480 3 CL01A310T-U 151153 10.00 16.00 RTA1-P 151194
OPEN 158163 575 3 CL01A310T-Y 151154 10.00 16.00 RTA1-P 151194
OPEN
15
142287 208 3 CL06A311M-L 151173 42.00 55.00 RTA2-G 151202
OPEN 142288 240 3 CL06A311M-S 151172 30.00 43.00 RTA2-E 151206
OPEN 142288 480 3 CL25A310T-U 151162 17.50 22.00 RTA1-T 151197
OPEN 142289 575 3 CL02A310T-Y 151158 14.50 18.00 RTA1-S 151196
OPEN
20
142295 208 3 CL07A311M-L 151176 54.00 65.00 RTA2-H 151203
OPEN 142296 240 3 CL07A311M-S 151175 42.00 55.00 RTA2-G 151202
OPEN 142296 480 3 CL04A310M-U 151167 25.00 32.00 RTA1-V 151199
OPEN 142297 575 3 CL25A310T-Y 151163 17.50 22.00 RTA1-T 151197
TEFC
1/2
159184 120 1 CL00A310T-J 151146 5.50 8.50 RTA1-M 151192
TEFC 159184 208 1 CL00A310T-L 151150 2.50 4.10 RTA1-K 151190
TEFC 159184 240 1 CL00A310T-S 151147 2.50 4.10 RTA1-K 151190
TEFC 16077 208 3 CL00A310T-L 151150 1.90 2.70 RTA1-J 151189
TEFC 16077 240 3 CL00A310T-S 151147 1.90 2.70 RTA1-J 151189
TEFC 16077 480 3 CL00A310T-U 151148 0.65 1.10 RTA1-F 151186
TEFC 105568 575 3 CL00A310T-Y 151149 0.65 0.90 RTA1-F 151186
TEFC
3/4
115860 120 1 CL01A310T-J 151151 10.00 16.00 RTA1-P 151194
TEFC 115860 208 1 CL00A310T-L 151150 4.00 6.30 RTA1-L 151191
TEFC 115860 240 1 CL00A310T-S 151147 4.00 6.30 RTA1-L 151191
TEFC 20371 208 3 CL00A310T-L 151150 1.90 2.70 RTA1-J 151189
TEFC 20371 240 3 CL00A310T-S 151147 1.90 2.70 RTA1-J 151189
TEFC 20371 480 3 CL00A310T-U 151148 1.00 1.50 RTA1-G 151187
TEFC 105569 575 3 CL00A310T-Y 151149 0.65 1.10 RTA1-F 151186
Motor
CODE 50 - Starter Contactor with line voltage coil
and Overloads (used on units mfgd prior to 2/03)
Type HP P/N volt ph Mfg No. P/N min max GE # P/N
TEFC
1
174993 120 1 CL01A310T-J 151151 10.00 16.00 RTA1-P 151194
TEFC 174993 208 1 CL00A310T-S 151147 5.50 8.50 RTA1-M 151192
TEFC 174993 240 1 CL00A310T-S 151147 5.50 8.50 RTA1-M 151192
TEFC 16080 208 3 CL00A310T-L 151150 2.50 4.10 RTA1-K 151190
TEFC 16080 240 3 CL00A310T-S 151147 2.50 4.10 RTA1-K 151190
TEFC 16080 480 3 CL00A310T-U 151148 1.30 1.90 RTA1-H 151188
TEFC 105570 575 3 CL00A310T-Y 151149 1.00 1.50 RTA1-G 151187
TEFC
1.5
94347 120 1 CL02A310T-J 151156 14.50 18.00 RTA1-S 151196
TEFC 94347 208 1 CL00A310T-L 151150 8.00 12.00 RTA1-N 151193
TEFC 94347 240 1 CL00A310T-S 151147 8.00 12.00 RTA1-N 151193
TEFC 101286 208 3 CL00A310T-L 151150 4.00 6.30 RTA1-L 151191
TEFC 101286 240 3 CL00A310T-S 151147 4.00 6.30 RTA1-L 151191
TEFC 101286 480 3 CL00A310T-U 151148 1.90 2.70 RTA1-J 151189
TEFC 105665 575 3 CL00A310T-Y 151149 1.30 1.90 RTA1-H 151188
TEFC
2
105572 120 1 CL04A310M-J 151165 21.00 26.00 RTA1-U 151198
TEFC 105572 240 1 CL01A310T-S 151152 10.00 16.00 RTA1-P 151194
TEFC 158165 208 3 CL00A310T-L 151150 5.50 8.50 RTA1-M 151192
TEFC 158165 240 3 CL00A310T-S 151147 4.00 6.30 RTA1-L 151191
TEFC 158165 480 3 CL00A310T-U 151148 2.50 4.10 RTA1-K 151190
TEFC 158166 575 3 CL00A310T-Y 151149 1.90 2.70 RTA1-J 151189
TEFC
3
111564 120 1 CL04A310M-J 151165 25.00 32.00 RTA1-V 151199
TEFC 111564 240 1 CL02A310T-S 151157 10.00 16.00 RTA1-P 151194
TEFC 159330 208 3 CL00A310T-L 151150 5.50 8.50 RTA1-N 151192
TEFC 159330 240 3 CL00A310T-S 151147 5.50 8.50 RTA1-N 151192
TEFC 159330 480 3 CL00A310T-U 151148 2.50 4.10 RTA1-K 151190
TEFC 111571 575 3 CL00A310T-Y 151149 2.50 4.10 RTA1-K 151190
TEFC
5
111567 240 1 CL04A310M-S 151166 17.50 22.00 RTA1-T 151197
TEFC 155048 208 3 CL01A310T-L 151155 14.50 18.00 RTA1-S 151196
TEFC 155048 240 3 CL01A310T-S 151152 10.00 16.00 RTA1-P 151194
TEFC 155048 480 3 CL00A310T-U 151148 4.00 6.30 RTA1-L 151191
TEFC 158170 575 3 CL00A310T-Y 151149 4.00 6.30 RTA1-L 151191
TEFC
7.5
105842 240 1 CL45A310M-S 151170 30.00 40.00 RTA1-W 151200
TEFC 158171 208 3 CL04A310M-L 151169 21.00 26.00 RTA1-U 151198
TEFC 158171 240 3 CL25A310T-S 151161 17.50 22.00 RTA1-T 151197
TEFC 158171 480 3 CL01A310T-U 151153 8.00 12.00 RTA1-N 151193
TEFC 158172 575 3 CL00A310T-Y 151149 5.50 8.50 RTA1-N 151192
TEFC
10
105846 240 1 CL06A311M-S 151172 30.00 43.00 RTA2-E 151206
TEFC 158173 208 3 CL04A310M-L 151169 25.00 32.00 RTA1-V 151199
TEFC 158173 240 3 CL04A310M-S 151166 21.00 26.00 RTA1-U 151198
TEFC 158173 480 3 CL01A310T-U 151153 10.00 16.00 RTA1-P 151194
TEFC 158174 575 3 CL01A310T-Y 151154 8.00 12.00 RTA1-N 151193
TEFC
15
142443 240 3 CL06A311M-S 151172 30.00 43.00 RTA2-E 151206
TEFC 142443 480 3 CL25A310T-U 151162 17.50 22.00 RTA1-T 151197
TEFC 142444 575 3 CL02A310T-Y 151158 10.00 16.00 RTA1-P 151194
TEFC
20
142301 240 3 CL07A311M-S 151175 42.00 55.00 RTA2-G 151202
TEFC 142301 480 3 CL04A310M-U 151167 25.00 32.00 RTA1-V 151199
TEFC 142302 575 3 CL25A310T-Y 151163 17.50 22.00 RTA1-T 151197
EE
1
105659 208 3 CL00A310T-L 151150 2.50 4.10 RTA1-K 151190
EE 159328 240 3 CL00A310T-S 151147 2.50 4.10 RTA1-K 151190
EE 159328 480 3 CL00A310T-U 151148 1.00 1.50 RTA1-G 151187
EE 158175 575 3 CL00A310T-Y 151149 1.00 1.50 RTA1-G 151187
EE
1.5
105662 208 3 CL00A310T-L 151150 4.00 6.30 RTA1-L 151191
EE 159329 240 3 CL00A310T-S 151147 2.50 4.10 RTA1-K 151190
EE 159329 480 3 CL00A310T-U 151148 1.90 2.70 RTA1-J 151189
EE 158162 575 3 CL00A310T-Y 151149 1.30 1.90 RTA1-H 151188
EE
2
105664 208 3 CL00A310T-L 151150 4.00 6.30 RTA1-L 151191
EE 159027 240 3 CL00A310T-S 151147 4.00 6.30 RTA1-L 151191
EE 159027 480 3 CL00A310T-U 151148 2.50 4.10 RTA1-K 151190
EE 158176 575 3 CL00A310T-Y 151149 1.90 2.70 RTA1-J 151189
EE
3
159186 208 3 CL00A310T-L 151150 8.00 12.00 RTA1-N 151193
EE 159028 240 3 CL00A310T-S 151147 5.50 8.50 RTA1-N 151192
EE 159028 480 3 CL00A310T-U 151148 2.50 4.10 RTA1-K 151190
EE 159030 575 3 CL00A310T-Y 151149 2.50 4.10 RTA1-K 151190
EE
5
159029 208 3 CL02A310T-L 151159 10.00 16.00 RTA1-P 151194
EE 159029 240 3 CL02A310T-S 151157 10.00 16.00 RTA1-P 151194
EE 159029 480 3 CL00A310T-U 151148 5.50 8.50 RTA1-M 151192
EE 111602 575 3 CL00A310T-Y 151149 4.00 6.30 RTA1-L 151191
EE
7.5
159331 208 3 CL04A310M-L 151169 21.00 26.00 RTA1-U 151198
EE 159332 240 3 CL25A310T-S 151161 17.50 22.00 RTA1-T 151197
EE 159332 480 3 CL00A310T-U 151148 8.00 12.00 RTA1-N 151193
EE 158164 575 3 CL00A310T-Y 151149 5.50 8.50 RTA1-N 151192
EE
10
159333 208 3 CL04A310M-L 151169 25.00 32.00 RTA1-V 151199
EE 159334 240 3 CL04A310M-S 151166 21.00 26.00 RTA1-U 151198
EE 159334 480 3 CL01A310T-U 151153 10.00 16.00 RTA1-P 151194
EE 158163 575 3 CL00A310T-Y 151149 10.00 16.00 RTA1-P 151194
EE
15
142440 208 3 CL06A311M-L 151173 30.00 43.00 RTA2-E 151206
EE 142441 240 1 CL06A311M-S 151172 30.00 43.00 RTA2-E 151206
EE 142441 480 3 CL25A310T-U 151162 17.50 22.00 RTA1-T 151197
EE 142289 575 3 CL02A310T-Y 151158 10.00 16.00 RTA1-P 151194
EE
20
159187 208 3 CL07A311M-L 151176 54.00 65.00 RTA2-H 151203
EE 142299 240 3 CL06A311M-S 151172 42.00 55.00 RTA2-G 151202
EE 142299 480 3 CL04A310M-U 151167 21.00 26.00 RTA1-U 151198
EE 142300 575 3 CL25A310T-Y 151163 17.50 22.00 RTA1-T 151197
Blower Motor Starters with Line Volt Coil - used before 9/03 (Serial No. Date Code BCI))
