Reznor ADFH Parts Manuals - Manual (Page 19)

Form P-ADF, P/N 270068 R1, Page 19
Model ADF 1200 with Vertical Discharge and Model ADFH 1200
Motor Horizontal
Discharge
Drive Option (See page 16.)
CODE 140 - Motor Sheave CODE 141 - Blower Sheave CODE 142 - Belt
HP Option P/N Mfr No. Bore P/N Mfr No. Bore P/N Mfr No.
1 AL6 V
AM 2, 3, 4 13580 1VL34
5/8
19111 AK64 1 124275 A93
AM 5, 6, 7, 8, 9 7962 1VL40 124641 AK74H* 124275 A93
1-1/2 AL7 V
AM 3, 4, 5, 6, 7 13580 1VL34
5/8
105484 AK71H* 1 124664 A90
AM 8, 9, 10, 11 105476 1VL44 124641 AK74H* 124275 A93
2 AL8 V
AM 5, 6, 7, 8, 9 106748
1VL40 7/8
124641 AK74H* 1 124275 A93
AM 10, 11, 12, 13, 14 106748 124642 BK60H* 115934 A89
3 AL9 V
AM 6, 7, 8, 9 106748 1VL40
7/8
113800 AK144H* 1 124667 A103
AM 10, 11, 12, 13 106758
1VL44
50520 AK134 124666 A101
AM 14, 15, 16, 17 106758 16153 AK104 124606 A97
5
AL10 V
AM 7, 8, 9, 10, 11 87500
2VP36
7/8
114034 2AK124H* 1 (2) 124665 A99
AM 12, 13, 14, 15 87500 89649 2BK100H* (2) 92313 BX93
AM 16, 17, 18, 19, 20 6599 2VP42 89649 (2) 92321 BX95
AL27 V
AM 7, 8, 9, 10, 11 7963
2VP42 1-1/8
89648 2BK80H* 1 (2) 124275 A93
AM 12, 13, 14, 15 7963 124844 2AK59H* (2) 115934 B89
AM 16, 17, 18, 19, 20 7963 89649 2BK100H* (2) 92321 BX95
7-1/2 AL11 V
AM 10, 11 110771 2VP65
1-3/8
113801 2AK104H** 1-3/16 (2) 124665 A99
AM 12, 13, 14, 15 106257 2VP60 16167 2BK90 (2) 92321 BX95
AM 16, 17, 18, 19 110771 2VP65 89648 2BK80H** (2) 92321 BX95
AM 20, 21, 22, 23, 24 114249 2VP71 89648 (2) 92321 BX95
10 AL12 V
AM 10, 11 110771 2VP65
1-3/8
113801 2AK104H** 1-3/16 (2) 124665 A99
AM 12, 13, 14, 15 106257 2VP60 16167 2BK90 (2) 92321 BX95
AM 16, 17, 18, 19 110771 2VP65 89648 2BK80H** (2) 92321 BX95
AM 20, 21, 22, 23, 24 114249 2VP71 89648 (2) 92321 BX95
15 AL15 V
AM 13, 14, 15, 16 89645 3MVP45B59
1-5/8
115723 3BK90H** 1-7/16 (3) 92334 BX96
AM 17, 18, 19, 20, 21, 22, 23, 24 89644 3MVP40B54 106262 3BK65H** (3) 92315 BX90
20 AL16 V
AM 13, 14, 15, 16 89645 3MVP45B59
1-5/8
115723 3BK90H** 1-7/16 (3) 92334 BX96
AM 17, 18, 19, 20, 21, 22, 23, 24 89644 3MVP40B54 106262 3BK65H** (3) 92315 BX90
*Use 1" Bore, "H" Bushing, P/N 92203; **Use 1-3/16" Bore, "H" Bushing, P/N 106260; ***Use 1-7/16" Bore, "H" Bushing, P/N 89659
Cabinet
Parts
Blower
(Discharge
Air) End -
ADF 300 with
Horizontal
Discharge
Illustrated
Burner (Inlet Air) End
150 - 154
155
156
160
158
160
CODE Description 300 500 700 1200
150 Cabinet Top
119490
(one piece)
123420 (burner section) 123422 (burner section)
123421 (blower section) 123422 (burner section)
151 Top Filler with Rubber Gasket (joins top sections) -- -- 115692
152 Cabinet Top Insulation
Burner Section 123025 123027 123029
Blower Section 123026 123028 149157 and 149158
153 Blower Section Top Inner Panel 124769 124772 124737
154 Burner Section Top Inner Panel 124770 124771 124773
155 End Panel (burner end) Assy (includes CODE 155A) 111990 111285 No assembled replacement; contact
distributor or factory for replacement parts. 155A Weatherhood Support Angle only 105011 105013
156
Outer End Panel (blower end)
ADF Horizontal 120321 119604 110095
ADF 300/500 Vertical 122875 123724 --
End Panel, single wall insulated ADFH & ADF 700/
1200 Vertical
103618 103620 103622
End Panel, double wall insulated 105548 105550 105552
157A Inner End Panel
Horizontal 120320 119605 -- --
Vertical (solid) 122874 123725 -- --
157B Top Front Panel (discharge end) Horizontal -- -- 105612
157C Bottom Front Panel (discharge end) Horizontal -- -- 120042
157D Corner Post (control side) Horizontal -- -- 105603
157E Corner Post (non-control side) Horizontal -- -- 105604
158 Discharge Duct Flange
Horizontal 176119 123404
(2) 110093 Sides
(2) 110092 Top/Btm
Vertical (bottom) 176119
123404 (2) 176119 (2) 123404
176118 123723 (2) 176118 (2) 123723
159 Burner Compartment Door Assy (non-control side)
122865 (single wall/insulated, non-control side)
125854 (double wall/insulated, non-control side)
160 Burner/Electrical Compartment Door Assy (control side) 123031
161 Blower Compartment Door Assy
(insulated; both sides of cabinet)
single wall (2) 100347 (2) 122865
double wall (2) 104115 (2) 125854
162 Door Latch Kit for all outer access doors 112974
NOTE:
If other
cabinet
parts are
required,
contact
the factory
Service
Dept.
Code 162 -
Replacement
Door Latch,
P/N 112974
