Reznor ADFH Parts Manuals - Manual (Page 18)

Form P-ADF, P/N 270068 R1, Page 18
Model ADF 700 - Horizontal Discharge
Open Motor Horizontal
Discharge Drive Option (See page 16.)
CODE 140 - Motor Sheave CODE 141 - Blower Sheave CODE 142 - Belt
HP Option P/N Mfr No. Bore P/N Mfr No. Bore P/N Mfr No.
1 AL6 H AM 5, 6, 7, 8 13580 1VL34 5/8 18797 AK64 1 65404 A51
1-1/2 AL7 H
AM 5, 6, 7, 8 13580
1VL34 5/8
18797 AK64
1
65404 A51
AM 9, 10, 11, 12, 13, 14, 15 13580 105481 AK46 65403 A48
2 AL8 H
AM 7, 8, 9, 10, 11 106748 1VL40
7/8
18797 AK64
1
50513 A52
AM 12, 13, 14, 15, 16 110125 1VP34 105481 AK46 65403 A48
3 AL9 H
AM 9, 10, 11, 12, 13 106758 1VL44
7/8
50520 AK134
1
16138 A63
AM 14, 15, 16, 17 106758 16153 AK104 50476 A58
AM 18, 19, 20, 21, 22 106748 1VL40 19111 AK84 16131 A54
5 AL10 H
AM 9, 10, 11, 12, 13 87500 2VP36
7/8
7955
2AK104
1
(2) 16134 A57
AM 14, 15, 16, 17 6599 2VP42 7955 (2) 50476 A58
AM 18, 19, 20, 21, 22, 23, 24 6599 1VL40 87504 2AK84 (2) 16132 A55
7-1/2 AL11 H
AM 12, 13, 14, 15 106257 2VP60
1-3/8
16167 2BK90
1-3/16
(2) 92223 B54
AM 16, 17, 18, 19 110771 2VP65 89648 2BK80H** (2) 92223 B54
AM 20, 21, 22, 23, 24 114249 2VP71 89648 (2) 92223 B54
10 AL12 H
AM 12, 13, 14, 15 106257 2VP60
1-3/8
16167 2BK90
1-3/16
(2) 92223 B54
AM 16, 17, 18, 19 110771 2VP65 89648 2BK80H** (2) 92223 B54
AM 20, 21, 22, 23, 24 114249 2VP71 89648 (2) 92223 B54
*Use 1" Bore, "H" Bushing, P/N 92203; **Use 1-3/16" Bore, "H" Bushing, P/N 106260
Model ADF 700 with Vertical Discharge and Model ADFH 700
Open Motor Vertical
Discharge Drive Option (See page 16.)
CODE 140 - Motor Sheave CODE 141 - Blower Sheave CODE 142 - Belt
HP Option P/N Mfr No. Bore P/N Mfr No. Bore P/N Mfr No.
1 AL6 V AM 5, 6, 7, 8 13580 1VL34 5/8 123761 AK64H* 1 92218 A83
1-1/2 AL7 V
AM 5, 6, 7, 8 13580
1VL34 5/8
123761 AK64H*
1
92218 A83
AM 9, 10, 11, 12, 13, 14, 15 13580 123763 AK46H* 92217 A81
2 AL8 V
AM 7, 8, 9, 10, 11 106748 1VL40 7/8 123761 AK64H*
1
92218 A83
AM 12, 13, 14, 15, 16 110125 1VL34 7/8 123763 AK46H* 92217 A81
3 AL9 V
AM 9, 10, 11, 12, 13 106758
1VL44
7/8
50520 AK134
1
124606 A97
AM 14, 15, 16, 17 106758 16153 AK104 124607 A92
AM 18, 19, 20, 21, 22 106748 1VL40 19111 AK84 92265 A88
5 AL10 V
AM 9, 10, 11, 12, 13 87500 2VP36
7/8
113801 2AK104H*
1
(2) 124610 A91
AM 14, 15, 16, 17 6599
2VP42
113801 (2) 124610 A91
AM 18, 19, 20, 21, 22, 23, 24 6599 123765 2AK84H* (2) 92265 A88
7-1/2 AL11 V
AM 12, 13, 14, 15 106257 2VP60
1-3/8
16167 2BK90
1-3/16
(2) 92315 BX90
AM 16, 17, 18, 19 110771 2VP65 89648
2BK80H**
(2) 92315 BX90
AM 20, 21, 22, 23, 24 114249 2VP71 89648 (2) 92315 BX90
10 AL12 V
AM 12, 13, 14, 15 106257 2VP60
1-3/8
16167 2BK90
1-3/16
(2) 92315 BX90
AM 16, 17, 18, 19 110771 2VP65 89648
2BK80H**
(2) 92315 BX90
AM 20, 21, 22, 23, 24 114249 2VP71 89648 (2) 92315 BX90
*Use 1" Bore, "H" Bushing, P/N 92203; **Use 1-3/16" Bore, "H" Bushing, P/N 106260
Model ADF 1200 - Horizontal Discharge
Open Motor Horizontal
Discharge
Drive Option (See page 16.)
CODE 140 - Motor Sheave CODE 141 - Blower Sheave CODE 142 - Belt
HP Option P/N Mfr No. Bore P/N Mfr No. Bore P/N Mfr No.
1 AL6 H
AM 2, 3, 4 13580 1VL34
5/8
19111 AK64
1
50476 A58
AM 5, 6, 7, 8, 9 7962 1VL40 124641 AK74H* 16134 A57
1-1/2 AL7 H
AM 3, 4, 5, 6, 7 13580 1VL34
5/8
105484 AK71H*
1
16133 A56
AM 8, 9, 10, 11 105476 1VL44 124641 AK74H* 50476 A58
2 AL8 H
AM 5, 6, 7, 8, 9 106748
1VL40 7/8
124641 AK74H*
1
16134 A57
AM 10, 11, 12, 13, 14 106748 124642 BK60H* 112531 B55
3 AL9 H
AM 6, 7, 8, 9 106748 1VL40
7/8
113800 AK144H*
1
16558 A69
AM 10, 11, 12, 13 106758
1VL44
50520 AK134 92408 A68
AM 14, 15, 16, 17 106758 16153 AK104 16138 A63
5 AL10 H
AM 7, 8, 9, 10, 11 87500
2VP36
7/8
114034 2AK124H*
1
(2) 114103 A65
AM 12, 13, 14, 15 87500 89649
2BK100H*
(2) 7872 B60
AM 16, 17, 18, 19, 20 6599 2VP42 89649 (2) 124654 B61
7-1/2 AL11 H
AM 10, 11 110771 2VP65
1-3/8
113801 2AK104H**
1-3/16
(2) 16137 A62
AM 12, 13, 14, 15 106257 2VP60 16167 2BK90 (2) 16143 B59
AM 16, 17, 18, 19 110771 2VP65 89648
2BK80H**
(2) 92226 B58
AM 20, 21, 22, 23, 24 114249 2VP71 89648 (2) 92226 B58
10 AL12 H
AM 10, 11 110771 2VP65
1-3/8
113801 2AK104H**
1-3/16
(2) 16137 A62
AM 12, 13, 14, 15 106257 2VP60 16167 2BK90 (2) 16143 B59
AM 16, 17, 18, 19 110771 2VP65 89648
2BK80H**
(2) 92226 B58
AM 20, 21, 22, 23, 24 114249 2VP71 89648 (2) 92226 B58
15 AL15 H
AM 13, 14, 15, 16 89645 3MVP45B59 1-5/8 115723 3BK90H*** 1-7/16 (3) 7872 B60
AM 17, 18, 19, 20, 21, 22, 23, 24 89644 3MVP40B54 106262 3BK65H*** (3) 92223 B54
20 AL16 H
AM 13, 14, 15, 16 89645 3MVP45B59 1-5/8 115723 3BK90H*** 1-7/16 (3) 7872 B60
AM 17, 18, 19, 20, 21, 22, 23, 24 89644 3MVP40B54 106262 3BK65H*** (32) 92223 B54
**Use 1-3/16" Bore, "H" Bushing, P/N 106260; ***Use 1-7/16" Bore, "H" Bushing, P/N 89659
Drive Tables by Model and Size (cont'd)
